Name: Mini Bidirectional 12G SDI Fiber Converter 515VDC SMF 20KM
Brand: E-link
Price: 999 USD

Brand Name : E-link

Model Number : LNK-M12G-1FV1BV-20

Certification : CE

Place of Origin : China

MOQ : 1pairs

Price : USD999/Paris

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 1000000Pairs/Month

Delivery Time : 3-5 working days

Packaging Details : Standard Carton Packaging

Product name : Mini Bidirectional 12G-SDI Fiber Converter

Resolution range : 3840*2160@60Hz

Input : 1 x 12G-SDI on BNC

Fiber : 11.88Gbps SMF 20KM

Output cable specification : ≤70m@12G SDI Belden 1694A

Optical transmission bandwidth : 270MHz~12GHz

Power : 5-15VDC

Dimensions (LxWxH) : 80 x 40 x 20 (mm)

Operating Temperature : -40℃~85℃

Warranty : 2 years

Contact Now

Mini Bidirectional 12G-SDI Fiber Converter

Product Description

Technical Indexes

Formats	Supports ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD) And ST-259(SD)
Compatible	Compatible With D VB-AS I and AES10 (MADI)
Transmitter	1 x Forward 12G-SDI on BNC
Transmitter	1 x Backward 12G-SDI on BNC
Receiver	1 x Forward 12G-SDI on BNC
Receiver	1 x Backward 12G-SDI on BNC
Fiber	11.88Gbps SMF 20KM
Supported Resolution	HDTV 4K*2K, 1080P, 1080I, 720P
Resolution range	3840*2160@60Hz
Input cable specification	≤70m@12G SDI Belden 1694A
Output cable specification	≤70m@12G SDI Belden 1694A
Optical transmission bandwidth	270MHz~12GHz
Power	5-15 VDC
Power Consumption	2 W (Max.)
Dimensions (LxWxH)	80 x 40 x 20 (mm)
Storage Temperature	-40℃~80℃
Operating Temperature	-40℃~85℃

Mini Bidirectional 12G SDI Fiber Converter 5-15VDC SMF 20KM
